Hikmicro Lynx 3.0 LH35 Thermal Monocular

Lynx 3.0 LH35 Thermal Monocular

Lynx 3.0 LH35 Thermal Monocular



35mm 15mK 384x288px Thermal
With a basic magnification of 3.4x, a 384x288 detector, and a 35mm F1.0 lens, the LH35 3.0 offers unparalleled performance for professional hunters and
mid-to-long-range applications.

Its 7.5° (13.1m at 100m) field of view and a detection range of up to 1800m ensure exceptional detail in vast, open spaces, making
it the ultimate choice for serious users seeking premium quality with proven shutterless technology.



Features:

High-sensitivity thermal module with NETD < 15 mK
35 mm, F1.0 lens with thermal detection range up to 1800 m
AI-powered Image Pro 3.0 and Zoom Pro algorithms
HIKMICRO Shutterless Image System (HSIS)
0.49-inch 1920 × 1080 resolution AMOLED display
Replaceable and rechargeable 18650 battery provides up to 4.5 hours of continuous operation at -20
Lightweight design at 354.5g, with a pocket-sized build







Specifications:


Thermal Module:


Image Sensor:
VOx Uncooled Focal Plane Arrays

Max. Resolution:
384 × 288

Frame Rate:
50 Hz

Pixel Interval:
12 µm

Response Waveband:
8 µm to 14 µm

NETD:
Less than 15 mK (@25°C), F#=1.0

Lens (Focal Length):
35 mm, F1.0

Focus Mode:
Focus Wheel

Min. Focusing Distance:
3.5 m

Magnification:
3.4 × - 27.2 × (8 ×)

Field of View (H xV):
7.5° × 4.6°/13.1 m × 8.0 m, Degrees / m @100 m

Detection Range:
1800 m

System:


Storage:
Built-in EMMC (64GB)

Record Video:
Yes

Capture Snapshot:
Yes

Local Album:
Yes

Standby Mode:
Yes

PIP:
Yes

Hotspot:
2.4/5 G WiFi Waveband

Hot Track:
Yes

Distance Measurement:
Yes

Audio Recording:
Yes

Power Supply:


Battery Type:
Replaceable and rechargeable 18650 battery

Battery Operating Time:
=5h (@25°C, WiFi on) =4.5h (@-20°C, WiFi on)

Type-C Power Supply :
5 V DC, 2 A Supports External Power Supply, Support Direct Charging

General:


Work Temperature:
From -30°C to 45°C (-22°F to 113°F)

Humidity:
Humidity: 90% or Less

Protection Level:
IP67

Dimension:
169.6 x 53.6 x 49.5 mm

Weight:
354.5 g with Battery



What's in the Box
Product 1
Battery Charger
Battery x 2
Lint-Free Cloth
Type-C Cable
Quick Start Guide
